Working Principle
Cooling pad operating principle: cooling pad work through an efficient and economic way that is
water evaporation . Dry hot air through the water into the room,
Due to the water hole walls evenly covered with water film, When
the outdoor fresh air through the water, water will absorb heat
from the air on the water and evaporation phenomenon so fresh air
temperature, humidity increased, through the cooling process, so
that the air is cool and moist facility.
Main Features
1.Special ripper process, corrugated paper has high intensity
structure
2.Use the imported 100% wood pulp, products involves surface active
agent, absorb water naturally, fast speed of pervasion lasting
effectiveness
3.Use special purpose water-proof cooling pad paper soaking resin,
corrosive resisitance, double service time
4.Fine percolation and absorbing water to ensure drip wet the wall
completely
5.Adopt stereoscopic structure can provide the largest evaporative
surface for the heating
exchanging between water and area
6Spatial crossing linking technology, cooling efficiency up to 85%
7.Varieties of type ,product can be customized.
8.offer you all technical assistance, help you make the perfect
greenhouse
Clean tap water or chilled water through a water inlet pipe to the
wet film humidifier lower circulation water tank, the water enters
the water tank is composed of float valve and liquid level switch
to control. The water in the water tank by a water pump to wet film
on top of the water distributor, through wet membrane water
distributor will be uniform water distribution, water under the
action of gravity along the wet membrane surface flow down the wet
film, wetting, penetrating, when the air through the wet wet film
during its increased humidity, temperature drop, another part
without evaporation water from the humidifier bottom back to the
water tank; the water in the water tank through a circulating water
pump using repeated cycles, the wet film humidification of air. So
as to achieve the purpose of saving water. When the circulating
water level in the water tank of water drop, switch to open, to
ensure water tank, the water level of the water tank is maintained
at a set height range; when the circulation of the water level in
the tank falls to a certain height, the water tank of the low water
level switch, ensure the circulating pump in the absence of water
stop. In the process of temperature and membrane water evaporated
part, but does not consume additional energy.
Air Conditioner Cooling pad for the chicken farm and house with CE
and reasonable price
About Evaporative cooling pad
Wet Film material is the core for the humidifier. It is a plant
fiber as the substrate, through the special composition of the
resin processing sintering to form corrugated plate-like
cross-overlapping polymer composite material, which contains slow
release type of antibacterial agent, with a strong water
absorption, a good self-cleaning ability, Non-toxic, resistant to
mold, fire and provide the largest contact between water and air
surface area.
Air Conditioner Cooling pad for the chicken farm and house with CE
and reasonable price
Main Specification:
High:1500mm/1800mm/2000mm
Width:600mm
Thickness:100mm/150mm/200mm
Air Conditioner Cooling pad for the chicken farm and house with CE
and reasonable price
Saturation efficiency definition
Humidification caused by changes in the state of the air near the
saturation line, expressed as a percentage, it is only with the
characteristics of wet film material itself, not because of wet
film inlet air changes in the state.
Saturation efficiency: η=tdb-to/tdb-twb
tdb= Temperature for the Dry bulb of Wet film inlet；
twb= Temperature for the wet bulb of Wet film inlet；
to = Temperature for the Dry bulb of Wet film outlet
E.g.: Air conditioning air volume of 50000m3 / h, heating capacity of
212KW, fresh air ratio of 30%. The air temperature is 24 ℃, the
relative humidity is 50%, the winter outdoor calculation parameter
is -4 ℃, 75%, the wet film thickness is calculated: outdoor -4 ℃,
75% air temperature after heating 38 ℃, Relative humidity of about
5%, check the enthalpy wet chart air wet bulb temperature of 15.7
℃.
Saturation efficiency: η=tdb-to/tdb-twb=38-24/38-15.7=62.8%
Thus we can choose the 150mm wet film to meet the humidification
requirement.
Air Conditioner Cooling pad for the chicken farm and house with CE
and reasonable price
From winery barrel room humidification to laboratory humidification
and greenhouse cooling,
Ucloud Fog systems are being used in wide variety of humidification
applications, evaporative cooling,
dust suppression and as disinfection equipment.
If you’re looking for a humidification system that…
Requires little maintenance
Prevents wet spots
Has a small droplet size
Offers low energy and water consumption
Intelligent precise humidity control
At Qingdao Ucloud Fog, you’ll find a range of humidification
systems that are suited to a variety of
different environments and applications. Whether you need a
commercial humidifier, industrial humidifier,
wine cellar humidifier or any other humidification system, Smart
Fog will engineer a solution to fit your
exact needs.
Air Conditioner Cooling pad for the chicken farm and house with CE
and reasonable price
